ilogic - structural beams and columns Бесплатно 3D Модель

this model consist of beams and h-columns. the beams and columns are modeled from a predefined list of sections. all parameters are driven from the included forms.

the list of predefined beams and columns:
100 ipe
100 ipe (aa)
120 ipe
120 ipe (aa)
140 ipe
140 ipe (aa)
152 x 152 x 23 h-column
152 x 152 x 30 h-column
152 x 152 x 37 h-column
160 ipe
160 ipe (aa)
180 ipe
180 ipe (aa)
200 ipe
200 ipe (aa)
203 x 133 x 25 i-beam
203 x 133 x 30 i-beam
203 x 203 x 46 h-column
203 x 203 x 52 h-column
203 x 203 x 60 h-column
203 x 203 x 71 h-column
203 x 203 x 86 h-column
254 x 146 x 31 i-beam
254 x 146 x 37 i-beam
254 x 146 x 43 i-beam
254 x 254 x 107 h-column
254 x 254 x 132 h-column
254 x 254 x 167 h-column
254 x 254 x 73 h-column
254 x 254 x 89 h-column
305 x 102 x 25 i-beam
305 x 102 x 28 i-beam
305 x 102 x 33 i-beam
305 x 165 x 40 i-beam
305 x 165 x 46 i-beam
305 x 165 x 54 i-beam
305 x 305 x 118 h-column
305 x 305 x 137 h-column
305 x 305 x 158 h-column
305 x 305 x 97 h-column
356 x 171 x 45 i-beam
356 x 171 x 51 i-beam
356 x 171 x 57 i-beam
356 x 171 x 67 i-beam
406 x 140 x 39 i-beam
406 x 140 x 46 i-beam
406 x 178 x 54 i-beam
406 x 178 x 60 i-beam
406 x 178 x 67 i-beam
406 x 178 x 74 i-beam
457 x 191 x 67 i-beam
457 x 191 x 74 i-beam
457 x 191 x 82 i-beam
457 x 191 x 89 i-beam
457 x 191 x 98 i-beam Для печати: Нет
